Carbide thermic drill bit Flowdrill standard short dia. 3.7 mm M4 with collar

Version

Item no: 1014754 103

Online price:
Catalogue price:

You save:

Will be ordered for you

Add to watch list

Quantity

Min. order quantity: 1

Add to basket

Description

Application
The thermic drill bit can be used in all common materials such as steel, stainless steel, aluminium, copper, brass and in high-strength special materials.

Execution

This tool creates a ring-shaped bulge on the surface, as the high-flowing material is simply beaded over
This produces a maximum passage length
A flowdrill is a carbide tool used to create additional wall thickness by displacing raw material
This locally produced extra material thickness can be used for a load-bearing thread, as a soldering and welding zone, for sealing surfaces or as a bearing point
The tool diameter can be between 1 and 40 mm and the wall thickness to be machined between 0.5 and 10 mm

Advantage

Localised increase in wall thickness
Sufficient thread length
Faster process cycle
High accuracy and long service life
Suitable for series production, e.g. on CNC
- Chipless

Technical data

Brand: FLOWDRILL
Thread dimension: M4
Core hole diameter: 3,7 mm
Min./max. material thickness: 1.0-1.8 mm
Shank diameter: 6,0 mm
Effective length: 8,2 mm
Min./max. rotation speed: 2400-2800 U/min(rpm)
Max. feed speed: 120 mm/min
Power rating: 0,7 kW
Cutting material: Carbide
Max. material thickness: 1,8 mm
Type: Short/standard
